Alcali Silica Reaction Test Water Bath
Alcali Silica Reaction Test Water Bath ; In this test chamber concrete specimen are stored at a temperature between 20°C and 70°C at nearly 100% rel.
Please Contact With Us For More Information
- Description
- Reviews (0)
- TECHNICAL SPECIFICATIONS
Description
| Product Code | Product Description |
| PRS-AALSILB | Alcali Silica Reaction Test Water Bath |
Alcali Silica Reaction Test Water Bath
STANDARDS : NF P18-454, RILEM Test Method TC 191-ARP (Ed.): AAR-4.1, ASTM C1567 -8, ASTM C1293 – 08b, CANADA CSA-A23.2-25A
In this test chamber concrete specimen are stored at a temperature between 20°C and 70°C at nearly 100% rel.
Humidity according to the French standard NF P18-454 (Décembre 2004) Detection of Potential Alkali-Reactivity- Accelerated method for testing aggregate combinations
using concrete prisms.
The temperature deviation herein is below 0.5K
Be the first to review “Alcali Silica Reaction Test Water Bath”
You must be logged in to post a review.
| Application | Storing of ACR test containers at 60°C and nearly 100% rel. Humidity according to RILEM/TC-ARP/01/20 and ASTM C1293 and modifies ASTM C1293 at 60°C |
| Net. size (lxwxh) | 550 x 1000 x 800 mm |
| Shelfs for the test container | 1 |
| Inner cabinet | Stainless steel |
| Sensors | PT100 1/10 DIN B |
| Heating | 2000 kW |
| Weight | App. 66 kg |
| Mains connection | 220 V 50 Hz |
